- UPS Capacity
1000 VA / 600 W
Entrada
Input Voltage Range
85 VAC to 150 VAC
Input Frequency
50/60 Hz self-adaptive
Plug Type
Type B (NEMA 5-15)
Salida
Output Frequency
50/60 Hz ± 0.5 Hz self-adaptive
Rango de voltaje de salida
110 VAC to 125 VAC
Transfer Time
= 10 ms
Waveform
PWM
Outlet Type
Type B (NEMA 5-15)
Outlet Number
Battery outletx4 Bypassx2
batería
Tipo de batería
12 V/9 Ah, lead-acid battery
Recharge Time
4-6 hours recover to 90% capacity
Typical Backup Time
Run time at 60w: 60 min
Run time at 150w: 15 min
Run time at 300w: 2 min
Interfaz
Communicate Ports
No
Protección
Full Protection
Surge protection, Overload protection, Discharge protection, Short circuit protection
indicador
pantalla
LED indicator
Working Mode (AC Mode): Solid green
Charging Mode (DC Mode): Solid red
Overloading Mode: Flashing yellow
Alarma
Charging Mode (DC mode): Sounding every 8 seconds
Low Battery: Sounding every second
Overloading Mode: Sounding every 0.5 seconds
Fault: Continuously sounding
General
Temperatura de funcionamiento
0 °C to 40 °C (32 °F to 104 °F)
Condiciones de humedad
30% to 90% (non-condensing)
Dimensión
274 mm × 95 mm × 139 mm (10.79" × 3.74" × 5.47")
Approx. 5.4 kg (11.9 lb)
1 cuota de $100005 (PTF: $100005)*
6 cuotas de $19322.5 (PTF: $115935)*
12 cuotas de $11283.75 (PTF: $135405)*
