- Oversea UPS
Built-in AVR
Super fast charging
Wide input voltage range
Overload protection
Short circuit protection
Surge protection
UPS Capacity
600 VA / 360 W
Entrada
Input Voltage Range
85 VAC to 150 VAC
Input Frequency
50/60 Hz self-adaptive
Plug Type
Type B (NEMA 5-15)
Salida
Rango de voltaje de salida
110 VAC to 125 VAC
Output Frequency
50/60 Hz ± 0.5 Hz self-adaptive
Transfer Time
= 10 ms
Waveform
PWM
Outlet Type
Type B (NEMA 5-15)
Outlet Number
Battery outletx4 Bypassx2
batería
Tipo de batería
12 V/7 Ah, lead-acid battery
Recharge Time
4-6 hours recover to 90% capacity
Typical Backup Time
Run time at 60w: 35 min
Run time at 100w: 20 min
Run time at 200w: 3 min
Interfaz
Communicate Ports
No
Protección
Full Protection
Surge protection,Overload protection,Discharge protection,Overcharge protection
indicador
pantalla
LED indicator
Working Mode (AC Mode): Solid green
Charging Mode (DC Mode): Solid red
Overloading Mode: Flashing yellow
Alarma
Charging Mode (DC mode): Sounding every 8 seconds
Low Battery: Sounding every second
Overloading Mode: Sounding every 0.5 seconds
Fault: Continuously sounding
General
Temperatura de funcionamiento
0 °C to 40 °C (32 °F to 104 °F)
Condiciones de humedad
30% to 90% (non-condensing)
Dimensión
274 mm × 95 mm × 139 mm (10.79" × 3.74" × 5.47")
Approx. 4.2 kg (9.26 lb)
